• Can be integrated in Casambi systems (Casambi Ready)
• Dimmable intrack constant current LED driver
• Selectable fixed output current between 250-600mA/350-700mA via DlP switch
• For luminaires of protection class ll
• Forms automatically a wireless communication network with up to 250 nodes
• Max. output power 24/28 W
• Terminal blocks: 45° push terminals
• Compact dimension, wide output current range
• Up to 87.5% efficiency
• Typ.power consumption on stand-by < 0.5 W
• Dimming range 1 to 100 %
• Life-time up to 50,000 hours
• 5-year guarantee
Type Input Voltage Output Power Output Voltage Output Current Ripple Tc Ta Dimension
VBD CC1 P28DCA40 DIP350-700mA IT 120-240V Max.28W 14-40V 350-700mA <5% 75℃ -20...+35℃ 166*31.4*43mm
VBD CC1 P24DCA40 DIP250-600mA IT 100-240V Max.24W 30-40V 250-700mA <5% 75℃ -20...+35℃ 166*31.4*43mm
